FRACTAL DESIGN skříň Meshify 2 Lite White TG Clear Tint, 2x USB 3.0, bez zdroje, E-ATX
Popis
Parametry
Meshify 2 Lite
The Meshify 2 Lite is a high-performance case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a front with a hinged, iconic mesh panel, and a spacious interior that supports multi-radiator setups.
- Iconic angular mesh design offers airflow with a bold, stealth-inspired aesthetic
- Spacious interior easily accommodates large motherboards up to and including 285 mm E-ATX
- Support for radiators up to 360 mm in front, 360 mm up top, or 280 mm in the base
TECHNICAL SPECIFICATIONS
| 3.5"/2.5" Universal drive mounts | 2 (included) |
| Dedicated 2.5" drive mounts | 2 included, 4 positions total |
| Expansion slots | 7 |
| Front interface (RGB version) | 2x USB 3.0, Audio I/O, Power button, RGB controller, USB type-C ready |
| Front interface (Standard version) | 2x USB 3.0, Audio I/O, Power button, Reset button, USB type-C ready |
| Total fan mounts | 9x 120/140 mm |
| Front fan (RGB verion) | 3x 120/140 mm (3x Aspect 14 RGB included) |
| Front fan (Standard version) | 3x 120/140 mm (2x Aspect 14 included) |
| Top fan | 3x 120/140 mm |
| Rear fan (RGB version) | 1x 120/140 mm (1x Aspect 14 RGB included) |
| Rear fan (Standard version) | 1x 120/140 mm (1x Aspect 14 included) |
| Bottom fan | 2x 120/140 mm |
| Dust filters | Top and bottom (mesh front) |
| Fixed velcro straps | Yes |
| Cable routing grommets | Yes |
| Captive thumbscrews | HDD, SSD and PSU brackets |
| Left side panel | Tempered glass |
| Right side panel | Steel |
| Compatibility | |
| Motherboard compatibility | E-ATX (max 285 mm)/ ATX / mATX / Mini-ITX |
| Power supply type | ATX |
| Front radiator | Up to 360/280 mm |
| Top radiator | Up to 360 mm |
| Rear radiator | 120 mm |
| Bottom radiator (RGB version) | Up to 240 mm |
| Bottom radiator (Standard version) | Up to 280 mm |
| PSU max length | 250 mm (with HDD cage installed) |
| GPU max length (RGB version) | 450 mm |
| GPU max length (Standard version) | 451 mm (476 mm without front fan) |
| CPU cooler max height | 185 mm |
| Cable routing space | 30 mm |
| Dimensions | |
| Case dimensions (L x W x H) | 542 x 240 x 474 mm |
| Case dimensions w/o feet/protrusions/screws | 541 x 240 x 454 mm |
| Net weight | 9.6 kg |
| Package dimensions (L x W x H) | 540 x 330 x 640 mm |
| Gross weight | 11.2 kg |
| Volume | 59 liters |
.
Provedení skříně:
Midi Tower
Počet pozic 3.5" (HDD):
2
Počet pozic 2.5" (SSD):
4
Vybavení PC skříně:
Bez integrovaného zdroje
Vybavení PC skříně:
Přední USB panel
Vybavení PC skříně:
Přední Audio panel
Bočnice:
Prosklená
