CHIEFTEC skříň Rackmount 4U ATX/mATX, UNC-409S-B, 400W PSF-400B, černá
Popis
UNC-409S-B
- 19” Rack chassis with 4U height
- Short Depth (<500mm) for ATX M/B
- Solid build quality with 1.2mm SECC steel
- Excellent Cooling
TECHNICAL SPECIFICATIONS
| Article No. | UNC-409S-B |
| Color | Black |
| Material | 1.2mm SECC |
| Motherboard support | Mini ITX, mATX, ATX |
| Dimension (DxWxH) | 482 x 480 x 177.5mm |
| Weight (without/with package) | 10.57 kg / 12.21 kg |
| Drive bay external | 3x 5.25” and 1x 3.5” |
| Drive bay internal | 2x 3.5” and 3x 2.5” |
| Power supply | PSF-400B (400W) Standard ATX PSU or installation of a 1+1 redundant PSU with included mounting kit |
| Front I/O | 2x USB 3.0 (USB3.2 Gen 1) |
| Scope of delivery | screw set, clamp-down bar for PCI-E cards |
| Expansion slots | 7 |
| Cooling Compatibility | Front: 2x 120mm fan Rear: 2x 80mm fan |
| CPU cooler height (max.) | 140 mm |
| VGA card length (max.) | 350 mm |
.
